What is Isogenopak Cladding?
At Buy Insulation Online, our focus has always been on bringing you facts on insulation along with top-quality insulating materials that will help make your home energy-efficient. We have always stressed the importance of lagging ducts, valves and pipe insulation along with the need to insulate walls, lofts and other parts of your home.
As we are aware by now pipes and ducts placed both indoors and outdoors need to be insulated. Additionally, insulated pipework placed outside requires proper protection from extreme temperature, humidity etc and this is where Isogenopak insulation or isogenopak cladding comes in play.
What is Isogenopak made of?
Isogenopak Rolls are made of PVC or Polyvinyl Chloride. It is one of the most popular polymers used worldwide for various applications. PVC is a strong, long-lasting, lightweight material.
Isogenopak rolls have excellent physical and chemical characteristics. Isogenopak is a rigid PVC film that is self-extinguishing and virtually impermeable to water. These materials remain free of water and oils and offer a smooth, dry fit around insulated pipes.
Isogenopak Cladding
Properties of Isogenopak:
Isogenopak insulation is resistant to changes in temperature. Its versatility makes it an excellent choice for both indoor and outdoor pipe insulation cladding, from -20degC to 65degC.
Isogenopak Rolls are an ideal solution for the protection of insulated pipes and ductworks. This material is tear-resistant, water-resistant, and self-extinguishing.
It is highly resistant to a corrosive atmosphere and will not corrode or degrade even when exposed to extreme temperatures. It is a lightweight rigid PVC film, suitable for jacketing insulated pipes, as it protects against vapours and flames. Additionally, it can prevent corrosion.
The inherent curl in isogenopak rolls makes it ideal for the quick covering of pipes. Its easy application makes it easy for even the untrained. Isogenopak is lightweight and easy to cut with a standard pair of scissors.
Aside from being fast and effective, Isogenopak is also cost-effective. It is available in flat sheets for use as duct insulation cladding and you can also buy matching tapes to complete an aesthetically pleasing install.
Isogenopak is also anti-static and easy to clean. Isogenopak is not paintable as this can negatively affect the fire performance of the product.
Its unique chemical properties make it an ideal solution for protecting pipes. Isogenopak can be purchased in rolls, bends, and end caps.
How to install Isogenopak Cladding on Pipes?
You measure the circumference of the pipe insulation, add on a 30 mm lap and cut the isogenopak roll with a standard pair of scissors. The circumferential seams should also overlap by 20-30 mm.
The film is then fixed to the insulated pipe using plastic rivets or a special solvent-based adhesive. The pre-formed S bends are then wrapped around the insulated pipe bends. The pre-formed S bends overlap 20-30 mm onto the adjoining straight pieces.
Isogenopak cladding is available in rolls and also flat sheets for use as a cladding material for insulated ducts. It's easy to handle and install, so this offers cost benefits over other methods of duct insulation cladding.
As mentioned above, the Isogenopak film has an inherent curl which allows it to be easily wrapped around spiral ductwork, it is easy to install on circular ductwork. You can choose to insulate square or rectangular ductwork as well. Its antistatic properties also make it suitable for use in food and beverage processing facilities.
In Conclusion:
As critical as insulating pipes and ductwork is in your facility, it is also equally important that you protect insulated pipes and ducts from harm by cladding them with appropriate cladding insulation. Isogenopak is perfect for the job. It is also cost-effective and very easy to work with.
