Isocheck Impact Mat acoustic flooring systems have been meticulously engineered to excel in reducing impact sound through timber floors and staircases. These systems have undergone acoustic tests, which are accepted for this specific purpose, although it's important to note that not all authorities endorse tests conducted with a soft floor covering on structural timber floors.
Isocheck Impact Mat 100: is a 6.5mm thick layer crafted from Isolate R (recycled rubber in a recipe for excellent impact improvement and dynamic stiffness) offers substantial improvements in impact sound reduction. It is ideal for use over floorboards, engineered floors, staircases, conversions, refurbishments or listed buildings requiring minimal structural change. It is 1200mm wide and 12.5M Long, weighing 39kgs per roll
Isocheck Impact Mat 200: is crafted from an 8mm Isofiba / barrier mat composite. Imapct Mat 200 is 1200 x 1000mm in dimension, with 8mm thickness of the resilient layer. Impact Mat 200 can be used a single layer or double layer over floorboards or
concrete decks for conversions, refurbishments or listed buildings that requires minimal structural change with a new plasterboard or existing lath and plaster ceiling.
Isocheck Impact Mat 300: is a tri-layer system with 12mm in thickness, featuring an Isopoli core that offers both impact and airborne noise improvements. Each roll is 1200 x 1000mm in dimension and is ideal for floor upgrades when looking to improve sound reduction on stairs and under engineered floors.
When these systems are properly installed as integral components of a complete party floor construction, they ensure that timber floors meet the stringent sound transmission standards specified in Approved Document E of 2003 and its subsequent amendments in 2004, 2010, 2013, and 2015.
These versatile systems are commonly employed beneath timber laminate floors and on staircases, offering various levels of airborne sound insulation based on their thickness and weight. In laboratory conditions, Isocheck Impact Mats 100 and 300 typically achieve impressive results of up to 30dB and 40dB, respectively.
The laboratory performance of Impact Mat 200 has been assessed at 26dB for a single layer. Moreover, on-site test results have consistently demonstrated favorable outcomes concerning Approved Document E requirements, particularly in enhancing airborne noise reduction alongside impact noise reduction.
Product Specification :
|
Impact Mat 100 |
Impact Mat 200 | Impact Mat 300 | |
| Overall size: | 1200mm x 12.5m roll | 1200mm x 1000mm | 1200mm x 1000mm mat 12.5kg/m2 |
| Resilient layer Thickness | 6.5 mm | 8mm Isofiba | 12 mm |
| Resilient layer: | 6.5mm Isolate R | Isofiba / barrier composite | 12.0mm tri-layer with Isofibre core |
| Weight : | 39kgs per roll (2.6kg/m2) | 8.0kg/m2 | 2.5kg/m2 |
Key Features:
- Designed for reducing sound transmission through timber floors and staircases.
- Ideal for floor upgrades, especially for improving sound reduction on stairs and beneath engineered floors.
- Ensures compliance with sound transmission standards outlined in Approved Document E from 2003 and its subsequent amendments.
- Versatile applications in new build, refurbishment, and conversion projects, including listed buildings with minimal structural changes.
- Isocheck provides a range of impact mats, including the Isocheck Impact Mat 100 (6.5mm thickness), Isocheck Impact Mat 200 (8mm Isofiba layer), and Isocheck Impact Mat 300 (12mm tri-layer system with Isofibre core) for various sound and impact reduction needs.
- Isocheck Impact Mat 200 can be draped over joists and placed beneath floorboards for single-layer applications.
Application:
Isocheck Impact Mats are ideally used for:
- New build projects.
- Refurbishments.
- Conversion projects.
- Especially suited for listed buildings where minimal structural changes are essential.
- It is intended for use in timber floors and staircases, making it a versatile choice for sound reduction in these contexts.
Certification:
The product is in compliance with Approved Document E of the Building Regulations.
Datasheets:
Isocheck Impact Mat 100 Datasheet
- Isocheck Impact Mat reduces sound in timber floors and staircases with excellent impact reduction.
- Complies with Approved Document E sound standards.
- Suitable for engineered floors and eco-friendly with recycled rubber.
- Applicable in new builds, refurbishments, and listed buildings.
- Designed for impact noise reduction and outstanding acoustics.
| Insulation Type | Acoustic Barrier Mat |
| Brand | Isomass |
| Product Code | Isomass Impact Mat - Acoustic Underlay |
| Length | 2400mm |
| Width | 600mm |
| Thickness Available | 32mm and 37 mm |
| Material |
Acoustic chip foam |
| Pieces Per Pack | 1 |
| Applications | Floor acoustics |
