PHS Apollo 2 Vapour Control Membrane is a high-performance solution designed to provide superior airtightness and vapour control for your building projects. Ideal for roof and wall constructions, this vapour control layer is essential for maintaining the integrity of your insulation and enhancing the overall energy efficiency of your structures.
Key Features:
- High Vapour Resistance: The PHS Apollo 2 has an optimum fixed vapour resistance level of Sd - 27m. This feature ensures an ideal level of vapour control by preventing diffusion of internal vapour into the building envelope back in winter and allowing diffusion in summer. This, in-turn prevents a build-up of condensed water vapour within the building envelope, that facilitates mildew growth and constructional damage
- Airtight Membrane: Achieve superior airtightness with the Apollo 2, reducing draughts and enhancing thermal performance.
- Durability: Constructed from premium materials, this VCL membrane offers long-lasting performance, even in demanding environments.
- Versatile Applications: Suitable for a range of applications, including attics, lofts and internal walls
Installing PHS Apollo 2 vapour barrier:
- This VCL membrane should be applied perpendicular to the direction of the application surface i.e. studs, rafters and joists.
- It should be fixed with PHS Double Sided Tape. PHS Argo joining Tape or a suitable PHS Grommet should be used for penetrations.
- For bonding barrier overlaps, penetrations and repair spots, PHS Argo or a similar tape is recommended.
- For connections to concrete or masonry PHS Internal Adhesive Sealant is recommended.
- Ensure there is a 100mm overlap of the membranes and tape with PHS Argo Tape or another suitable tape.
- The vapour barrier is 1.5 wide and 50m Long. Covers 75 Sqm
- Enables airtightness and vapour control in roof and wall constructions.
- CE approved vapour control layer (according to DIN EN 13984)
- Has an optimum fixed vapour resistance level of Sd - 27m
Product Type | Vapour Control Layer |
Brand | PHS |
Product Code | Apollo 2 |
Length | 50 M |
Width | 1.5 M |
Coverage | 75 Sqm |
Resistance To Water Penetration | W1 |
Sd Value | 0.029m |
Reaction To Fire | Class E |
Low temperature stability (no cracking at) | -60*C |
Applications | For use on insulated walls and pitched roofs |
Delivery Terms | |
---|---|
Order Value (Ex VAT) | Delivery Charge (Ex. VAT) |
£325.00 | Free Delivery |
Below £325 | £14.00 - £19.00 (Depending on postcodes) |
Returns, Cancellations and Refunds:
- You are free to cancel your order before we send you an order confirmation email and get a full refund
- Once the order is confirmed and an estimated delivery date is issued via email, Orders cannot be cancelled.
- Incorrectly ordered Goods can be returned within 14 days of delivery at our discretion. The customer is responsible for ensuring the goods are returned back to the address provided, in good condition where they will be inspected prior to processing any refunds.
- For incorrect, damaged or faulty products, please contact us immediately after you receive delivery and we will assist accordingly.
Customer Reviews
“ Best price and the product arrived next day. Happy with my purchase”Maxim G Verified Buyer
Our Customers Include
The PHS Apollo 2 Vapour Control Membrane is an effective moisture management solution designed for timber frame houses and extensions. With a fixed SD value of 27, it prevents moisture penetration, reducing the risks of mould and rot. Its durability allows it to withstand extreme temperatures down to -60°C. This membrane improves energy efficiency by creating an airtight barrier, which can lower energy bills. It covers 75 square meters and is easy to install with proper alignment and sealing techniques. For further insights into applications and technical specifications, keep exploring the details of this essential product.
Key Takeaways
- The PHS Apollo 2 is an effective vapour control membrane designed for timber frame houses and extensions.
- It features a fixed SD value of 27, preventing moisture penetration and reducing risks of mould and rot.
- The membrane enhances energy efficiency by creating an airtight envelope, lowering energy bills.
- It is CE approved according to DIN EN 13984 standards, ensuring high quality and reliability.
- The membrane measures 1.5m wide by 50m long, covering a total area of 75 square meters.
Overview of Apollo 2
When it comes to managing moisture in timber frame houses and extensions, the PHS Apollo 2 vapour control membrane stands out as an effective solution. This internal vapour control membrane's design targets floors, walls, and lofts, guaranteeing your home stays protected from moisture damage.
With a fixed SD value of 27, it effectively prevents moisture penetration, reducing the risks of mould and rot, which can be a concern in many households.
Moreover, the Apollo 2 membrane plays a significant role in enhancing energy efficiency. By achieving excellent airtightness, it helps lower energy bills while improving overall comfort within your living space.
Its dimensions of 1.5m wide and 50m long allow it to cover an impressive area of 75 square meters, making it suitable for various applications in both residential and commercial buildings.
Durability and low-temperature stability guarantee peak performance in different climates, giving you peace of mind.
Plus, the membrane is CE approved according to DIN EN 13984 standards, so you can trust its quality.
Key Features
Among the standout qualities of the PHS Apollo 2 Vapour Control Membrane are its impressive vapor resistance and durable construction. With a fixed vapour resistance level of Sd 27m, this membrane effectively prevents internal vapour diffusion during winter while allowing for diffusion in summer.
You'll appreciate how it maintains a balanced environment in your building, enhancing comfort and energy efficiency.
The durable construction from premium materials guarantees high performance, even in extreme conditions down to -60°C without cracking. This resilience means you can trust it in various applications, whether on timber frame roofs, walls, or ceilings, as well as in masonry construction.
One of the key features is its ability to create an airtight envelope, minimizing warm air loss and reducing draughts. This not only improves energy efficiency but also plays a vital role in moisture control.
By regulating moisture levels within the structure, the membrane helps mitigate risks of mould, rot, and mildew growth.
Choosing the PHS Apollo 2 means investing in a solution that prioritizes your comfort and the longevity of your building.
Installation Guidelines
When installing the PHS Apollo 2 membrane, make certain you position it perpendicular to the studs, rafters, and joists for the best alignment.
You'll want to overlap the membranes by 100mm and use PHS Argo Joining Tape to seal any overlaps and penetrations effectively.
Keeping reasonable tension on the membrane and removing creases will help guarantee peak performance and airtightness.
Proper Membrane Orientation
To guarantee ideal performance of the PHS Apollo 2 membrane, install it perpendicular to the studs, rafters, and joists. This orientation improves membrane efficiency, helping to overcome common installation challenges.
Make sure to roll out the membrane with the graphics facing outward; this indicates the warm side of the insulation.
For a secure fit, use PHS Double Sided Tape to adhere the membrane, ensuring it maintains its airtight qualities throughout its lifespan. It's essential to achieve a 100mm overlap between membrane sections for proper sealing.
Use PHS Argo Joining Tape to effectively seal these overlaps and any penetrations, preventing moisture intrusion.
While installing, maintain reasonable tension in the membrane and take care to remove any creases. These small details can help avoid potential moisture-related issues in the future.
By following these guidelines, you're not only ensuring peak performance but also contributing to the overall success of your project.
Remember, a well-installed membrane protects your space, promoting a healthier environment and improving energy efficiency.
Overlap and Sealing Techniques
Proper overlapping and sealing techniques are essential for maximizing the performance of the PHS Apollo 2 membrane. To guarantee effective moisture management, you should maintain a 100mm overlap between the membrane sections. This overlap is necessary for creating a secure seal that prevents moisture intrusion.
Use PHS Argo Joining Tape for all overlaps, penetrations, and repairs; this tape helps maintain airtight integrity throughout your installation.
When connecting the membrane to masonry, apply PHS Internal Adhesive Sealant. This step is important for achieving a robust seal that further reduces the risk of moisture entering your space.
Here are key tips to remember:
- Roll out the membrane on the warm side of the insulation, with the graphics facing outward for proper installation.
- Keep reasonable tension in the membrane to avoid creases, ensuring maximum airtightness and vapor control.
- Regularly check your sealing methods to confirm they're effective and up to standard.
Application Instructions
Installing the PHS Apollo 2 vapour control membrane requires careful attention to detail for best performance. First, store the membrane in dry conditions, keeping temperatures between +5°C and +25°C. This guarantees membrane durability before you start installation.
When applying the membrane, position it perpendicular to studs, rafters, and joists. This orientation is vital for peak performance and helps you avoid common installation challenges.
Secure the membrane using PHS Double Sided Tape, which provides reliable adhesion, assuring a good fit. For overlaps and penetrations, use PHS Argo Joining Tape. This tape is essential to effective moisture control and sealing, preventing any potential leaks.
Remember to follow the 100mm overlap guideline with tape for all seams. This step improves the membrane's airtightness and vapour control capabilities, creating a robust barrier against moisture.
Technical Specifications
With the installation steps covered, it's important to understand the technical specifications of the PHS Apollo 2 Vapour Control Membrane. This membrane is designed for effective moisture management, making it a reliable choice for your construction needs.
Here are some key specifications to note:
- Size: The membrane comes in a width of 1.5m and a length of 50m, providing a total coverage area of 75m².
- Vapour Resistance: With a fixed vapour resistance level of Sd 27m, it prevents internal vapour diffusion during winter while allowing it to escape in summer.
- Zp Value: The Zp value is 142.10 S.Pa/kg, enhancing its effectiveness in regulating moisture within your building environment.
Furthermore, the membrane's core diameter of 72mm guarantees compatibility with standard building materials and practices.
It also complies with CE certification according to DIN EN 13984 standards, which speaks to its reliability and performance metrics in construction applications.
Delivery and Returns
When you order the PHS Apollo 2 Vapour Control Membrane, understanding delivery charges is essential, especially since you can get free delivery for orders over £325.
If you need to return your product, remember that you have 14 days to act if the order was incorrect or damaged.
Plus, for local customers, there are convenient Click & Collect options available during the week.
Delivery Charges Explained
Understanding delivery charges is essential for a smooth shopping experience. Knowing how delivery pricing works can help you make informed decisions while shopping for your PHS Apollo 2 Vapour Control Membrane.
Here's what you need to know:
-
Free delivery is available for orders exceeding £325 (ex VAT).
-
Charges for smaller orders vary based on weight and postcode, ranging from £14 to £19.
-
Different weight categories influence delivery costs: £9 for small items (up to 2Kg), £11 for items (up to 5Kg), £13 for medium items (up to 15Kg), and £18 for large items (up to 20Kg).
Returns Process Overview
Managing the returns process can seem intimidating, but it's straightforward with a few key guidelines. First, if you need to cancel your order, do it before you receive a confirmation email for a full refund. For incorrectly ordered goods, you can return them within 14 days, as long as they're in suitable condition.
If you receive an incorrect, damaged, or faulty product, it's crucial to contact us immediately to kickstart the returns process. This quick action helps guarantee your customer satisfaction, as we want you to feel valued and supported in your purchase.
Be mindful that delivery charges vary based on your order total, ranging from £14.00 to £19.00 for orders below £325 (ex VAT), while orders over that amount qualify for free delivery.
Also, not all products are eligible for returns, so reviewing the full return policy before making a purchase is a wise move.
Collection Options Available
After addressing the returns process, it's important to explore the collection options available for your orders.
For those of you living nearby, the Click & Collect service offers a great way to enjoy collection convenience. You can pick up your orders from Monday to Friday, which makes it easy to fit into your schedule.
However, be aware that immediate availability for collection isn't currently an option due to stock status. You'll receive an email alert when the PHS Apollo 2 membrane is restocked and ready for you to collect.
Here are some key points to keep in mind:
- Collection is only available for local customers, enhancing local availability.
- Confirm you're ready to pick up your order promptly once notified of restock.
- Check your email regularly for updates regarding your order status.
Additional Products
When it comes to enhancing your construction projects, the PHS Apollo 2 offers a range of additional products designed to improve moisture control and airtightness.
You'll find the PHS 120 Roof Breather Membrane, priced at £60.00, which provides excellent moisture management for roofing applications. For securing and sealing membranes, consider the PHS Double Sided Butyl Tape (25mm x 30m) at just £9.20, ensuring strong adhesion that complements product compatibility.
If airtightness is your goal, the Gerband 586 Airtightness Tape (25m long) is available for £11.20, making it an essential addition to your toolkit.
For more extensive vapour control needs, the PHS Sd Variable Plus Airtight Membrane (1.5m x 50m) is offered at £199.99, catering to various project requirements.
To make your purchasing experience easier, flexible payment options are available, allowing you to spread the cost of these additional products over 45 days with no interest or fees.
Benefits of Apollo 2
Incorporating the PHS Apollo 2 Vapour Control Membrane into your construction projects brings a wealth of benefits that improve both energy efficiency and indoor air quality.
This membrane features a fixed vapour resistance of Sd 27m, effectively preventing internal vapour diffusion in winter and minimizing moisture-related issues. By creating a robust airtight envelope, it significantly reduces energy loss, helping to lower your energy bills while enhancing overall building comfort.
Here are some key benefits you'll enjoy:
-
Durability: The Apollo 2 is designed to withstand demanding environments, ensuring long-term performance in both residential and commercial buildings.
-
Mould Prevention: This membrane maintains insulation effectiveness while minimizing the risks of mould and rot, promoting a healthier indoor environment.
-
Versatility: Suitable for various applications, including timber frame roofs, walls, and ceilings, it's an ideal choice for energy-efficient building projects.
Contact Information
For any inquiries about the PHS Apollo 2 Vapour Control Membrane, you can easily reach out to Passive House Systems Ltd at (+353) 0214872664.
Their customer support team is available Monday to Friday, from 8 am to 5 pm, with a break from 1 pm to 1:30 pm. During these hours, you can get assistance with product ordering, technical specifications, and installation guidelines.
You'll find that the team is dedicated to guaranteeing you have all the information you need to make informed decisions.
If you're curious about additional products or special offers, don't hesitate to ask during your call. They're always happy to provide details that can improve your experience.
Your feedback is important to them, as it helps enhance their services and product offerings.
By sharing your thoughts, you contribute to a community that values quality and innovation.
So, whether you have questions or suggestions, reaching out is a great way to engage with Passive House Systems Ltd.
They're here to support you and guarantee your experience with the PHS Apollo 2 Vapour Control Membrane is a positive one.
Frequently Asked Questions
Do I Need a Vapour Barrier Membrane?
You definitely need a vapour barrier membrane! It offers essential vapour barrier benefits, ensuring proper moisture management solutions. Protect your home from mould and damage, keeping your space comfortable and energy-efficient for you and your loved ones.
Is a Vapour Control Layer Necessary?
Yes, a vapour control layer's necessary for effective moisture management and energy efficiency in your building. It keeps your space comfortable, protects against mould, and helps you save on energy bills, creating a healthier environment.
Is a Breather Membrane the Same as a Vapour Control Layer?
No, a breather membrane isn't the same as a vapour control layer. While both manage moisture, their functions differ significantly. Understanding these vapour layer differences helps you guarantee your building stays comfortable and efficient.
What Can I Use as a Vapour Control Layer?
You can use materials like polyethylene sheeting or specialized membranes with low vapor permeability for effective moisture management. These options help keep your space dry and comfortable, ensuring you create a welcoming environment for everyone.
Conclusion
In summary, the PHS Apollo 2 vapour control membrane offers reliable protection against moisture, ensuring the longevity of your building materials. Its key features, straightforward installation guidelines, and technical specifications make it an excellent choice for various applications. By choosing Apollo 2, you can improve your project's durability and efficiency. For more information on delivery options or additional products, don't hesitate to reach out. Investing in Apollo 2 is a smart step toward better moisture management.
