Self Regulating Trace Heating Cable For Frost Protection
Request a Quote
Our team is happy to fulfil custom orders, offer special bulk discounts you cannot get from the website. Please get in touch today to discuss your needs.
Trace heating cables provide effective freeze protection and help maintain the temperature in pipes. Self-regulating heating cable protects pipes from expensive freeze related damage it also helps ensure a constant temperature in the pipes. It is especially useful in industrial applications where a slight change in temperature can cause viscosity and flow issues.
Solco Pyrolec’s HSR self-regulation heating cable helps in frost protection of water pipelines and in hot water maintenance applications. It protects the pipework in your facility from extreme temperatures. It keeps issues like pipe freezing, bursts, sweating and others to a bare minimum.
The trace heating cable self-regulates thermal performance in response to temperature. The soft power switching feature of the product improves energy savings and efficiency, giving it long service life.
Product Specifications:
- Length: 1m, 5m, 10m, 20, 25m, 50m, 75m, 100m and 200m
- Maximum maintain temperature (Power-on) - 65° (150°F)
- Maximum continuous exposure (Power-off) - 85° (185°F)
- Rated Voltage: 200 - 277 Vac
|
Model |
Power Output at +10° |
Dimension |
For Pipework diam |
|
HSR102 |
10w/m |
11.2mm x 5.6mm |
Upto 80mm |
|
HSR162 |
16W/m |
11.2mm x 5.6mm |
100mm-250mm |
|
HSR242 |
24W/m |
11.2mm x 5.6mm |
100mm-250mm |
|
HSR302 |
30W/m |
13.6mm x 5.6mm |
100mm-250mm |
Key Features:
- Trace heating cable will not burn or overheat even when overlapped.
- It self-regulates thermal performance in response to temperature.
- Trace heating cables effectively prevent freezing, bursts and other issues.
- Trace heating cables can be cut to any length to suit any installation condition.
- Self-regulating trace heat cable has independent heat output control along its length.
- Soft (power) switching (which improves energy savings and efficiency) and gives a longer service life.
- Easy connection for powering and splicing.
Applications:
- Solco Pyroelec HSR Self-regulating heating cables offer the best performance in the following applications:
- Freeze protection of water pipelines
- Temperature maintenance for petrochemical and gas plant(s)
- Hazardous Ex locations, Ex e IIC Gb, ATEX Certifed
Product Details:
- Temperature Classification (T Rating): T6 (85°)
- Bus Wire – ASTM B355 Class 2 NPC AWG16
- Outer Jacket: FR polyolefin (CP)
- Suitable For: 230 Vac rated products
Please Note:
For heating cables for 110 Vac product range and customised length of heating cable, email us your request at enquiries@buyinsulationonline.co.uk
- Prevent frozen pipes with high-performing trace heating cables
- A self-regulating heating cable automatically regulates the temperature.
- Heat tracing cables also help maintain water temperature in pipes. Saves energy.
- CE approved
- Trace heating cables available in 1m to 200m lengths
- Protect pipework and insulation from extreme temperatures.
| Product Type | Trace Heating Cables |
| Product Code | HSR |
| Length | 1m, 5m, 10m, 20, 25m, 50m, 75m, 100m and 200m |
| Maximum maintain temperature (Power-on | 65° (150°F) |
| Maximum continuous exposure (Power-off) | 85° (185°F) |
| Rated Voltage | 200 - 277 Vac |
| Application | For frost protection |
